Almost there...

This is my last fall semester as a college student.

Wow.

Automated Generation of Javadocs for Open Source Android Applications

While Java is not my favorite language, it has its benefits. With one Android application already posted on the market and another application in development, I decided to start using Javadocs a little more seriously. The process of generating Javadocs is not that complicated using Eclipse, but that is not the solution I wanted. My goal was to automate the generation and posting of the docs as the source code changed.

My shared web host was suitable for hosting the html files, but not running javadoc to actually generate new documents. The solution I came up with was to automatically download the latest code from my public repository, generate the javadocs, and then upload the html files to my shared host. The computer I executed this code on was a Linux virtual server that I have sitting around. The process was actually very simple:

1. Clean up any files from the previous run of the script
2. Download the latest source code from the svn repository using svn export. It is notable that you can use svn export with Github since they support accessing repositories using the SVN protocol. Awesome!
3. Generate the javadocs based off of the freshly downloaded code using the desired parameters.
4. Copy the newly generated javadocs to the desired server. For my purposes, secure copy was the best solution. With my server's public key installed on the shared host, I was able to log into the remote box without prompting for a user name and password.

The final step in the process is to simply run the script nightly with a cron job and the javadocs will always be up to date. Since I was generating documents for Android applications it was important that the Android jar file be located on the server and the javadoc command be made aware of its location. Without this jar file, the generated javadocs would be incomplete. It is necessary that the Java code can actually be compiled on the computer where the javadoc command is run.

Here is the bash script with the file paths changed to protect the innocent:


#!/bin/bash
cd /path/to/files/docs/
rm -rf ampted.svn
rm -rf ampted

svn export http://ampted.googlecode.com/svn/trunk/
mv trunk ampted.svn

JAVADOCHEADER='<a target="_top" href="http://www.amptedapp.com/">Android Mobile Physical Therapy Exercise Documenter</a>'
JAVADOCFOOTER="Generated on `date`"
javadoc -private -header "$JAVADOCHEADER" -footer "$JAVADOCFOOTER" -d /path/to/files/docs/ampted/ -sourcepath /path/to/files/docs/ampted.svn/android/src/ -subpackages com.AMPTedApp -classpath /path/to/files/lib/android.jar

scp -r /path/to/files/docs/ampted remoteuser@example.com:/path/to/remote/files/docs/


This process has one point where it could definitely be improved and that is that it always overwrites the javadocs even if the source code did not change. If a check was added that compared the commit number of the previously generated documentation and only generate and upload a new copy if it is newer. This wasted effort is not a major concern for small projects, but may need to be fixed as my projects grow in size.

You can see the docs for AMPTed, which is a project that is in the very early stages of development, at http://javadocs.amptedapp.com/

Nothing to do, so what will I accomplish?

There are two and a half weeks before my last fall semester starts and I have very little to do. I have a few things on my calendar, but generally it is empty. So, what I am going to do with all of this free time? Simple, write lots and lots of code. Actually, my plan is to work on several projects while I still have the time. It just happens to be that most of these projects involve me writing code.

The main projects that I will be working on include creating DPX Answers for DyKnow Panel Extractor, creating the foundation for AMPTed App, fixing bugs and making small improvements to OpenNoteSecure, and implementing the NAESC Conference registration website. These are high level items on my to-do-list. I plan on making a low level to-do-list that will help me get my ideas organized.

It is a rare for me to have this much free time, so I plan on putting myself to work and making some major progress. I've already managed to code quite a bit, including some major improvements to other projects that are not on the above list. I just need to find a nice quiet place to sit down and start working and not move until I have a plan of action.

Some Web Server Management and a Plan for Backups

It has been quite a while since I spent some time administering my personal websites. My sites are hosted using GoDaddy's shared host, which isn't as bad as some of the reviews make it out to be. The big thing that I have been putting off is implementing a reliable and automated backup system. My previous strategy for backups was to simply dump the databases and copy down all of the files once a month, if I remembered. It would not be easy to replace the content of my websites if it were to be lost.

The first step on developing my backup strategy was to clean up my content and current installs. I deleted some web applications and code that I was playing with, but no longer used. These applications were some things that I was playing around with, but never did anything with. Once I did that I made a backup of everything by hand and then upgraded all of my web apps to the latest version. I was now ready to develop my automated system.

The first step was to get a local backup on the web server itself. This was done through shell access to the server using SSH and developing a shell script that performed all of the necessary steps. The two things that need to be backed up were the databases and the actual files. The MySQL databases are simple to backup using the mysqldump command and compressing the output and storing it to a file. The files can be backed up using a simple tar command which can also compress the files down to a reasonable size.

Once all of my database and files were compressed and organized, I took them all and packaged them up in another tar which was my final backup, a single file. This script was set to run as a cron job and the automated backup process was half way complete. The only thing left to do was to find a way to transfer the backup off-site.

My first though was to copy the backup to my personal Linux server. I eventually found a way to automate this process using scp and was happy with the results. It would have been fairly simple to automate this process, but it just didn't seem to be the solution I was looking for. The solution I went with was to store the backups on Amazon S3 using s3-bash. S3 provided very cheap storage and was easily accessed using open source tools that made the process of transferring files very painless. My estimates place the total cost of backups that will be stored on S3 at less than $0.40 a month!

Deciding to use a paid service meant that it would not be logical to store all of my backups indefinitely, and I needed to come up with a plan on how long to keep each backup. I also needed some way to delete backups after they were no longer needed. The solution I came up with was extremely simple. The backup script would run every night and generate and transfer the complete backup, about 45 MB, to the S3 servers. My plan was to keep the backup created on the first of each month for a year, this way I'll avoid data loss if something went wrong that was a long term problem. Additionally, I would keep a backup for each day of the week helping me to avoid loss of data in the short term. After 12 months of operation I would have a total of 19 backup files that would continue to be replaced as time went on. The old backups would not need to be deleted, because by uploading a file with the same key (or file name) it over writes the older version, thereby deleting the old backup.

My backup script has only been running for a few days, but I am very pleased with the results. I still want to do some testing to insure that by backups are comprehensive, but initial inspection shows reveals no problems. This set it and forget it approach is exactly what I was hoping to implement.

The Finish Line is in Sight - Summer 2010

This semester is unique in that I have a large number of projects & papers that I will have completed. Two of the projects are for the classes I am taking this semester and the other two are papers that I hope to have published. I've already heard the good news about one of the papers and will learn about the fate of my other paper in August. First my class projects...

OpenNoteSecure is an Android application that I created for my CECS 564 Cryptology Term Paper. The goal of the application was to store information securely on an Android phone using encryption. The paper I have written about the project, Storing Encrypted Plain Text Files Using Google Android, is almost finished and I will post it to my website after the semester is over. This is my first Android application that I have created and it is available on the Android Market. I have learned a lot about using cryptology libraries and developing Android applications through this project.

This semester I am also taking IE 563 Experimental Design, a class that has proved to be very useful. My project for that class was testing the accuracy of Window's handwriting recognition software. The source code I used (other than the database schema) was included as part of DPX and is available in the subversion repository. The paper about the project, tentatively titled An Analysis of Type II Errors Using Windows Handwriting Recognition on Individual Words and Numbers, covers the statistical analysis based on the data I collected from handwriting samples. After this semester is over I also plan on posting this paper along with the source code, executable, and some instructions to my website.

The paper that I coauthored with three of my classmates comparing my groups capstone project to another similar project was accepted by CGames 2010. Our paper, Comparing Multiple Game Engine Designs To Develop A Unified, Abstract Layer For Supporting Multiple Game Play Scenarios, discusses a method for abstracting the common elements of our game engines and proposes a new design pattern. Both projects were unique in that they implemented game engines and the similarities and differences between the two projects are very interesting. We will be attending the conference here in Louisville where we will present our paper. Luckily, the conference falls after the semester is over so there will be time to prepare our presentation and attend the conference.

Lastly, and probably what I am most proud of, was the paper that I submitted to WIPTE 2010. Titled, A Method For Automating The Analysis Of Tablet PC Ink Based Student Work Collected Using Dyknow Vision, my paper discusses a tool I developed, DPX Grader, for automatically extracting handwritten scores form panels. My goal is to use what I learned from my analysis of handwriting recognition in the above mentioned class project to develop a tool I am calling DPX Answers that extends what I have done with DPX Grader. My goal is to semi-automate the grading process of student work submitted using a Tablet PC. This is rather ambitious, but I am excited to start major development during the break between semesters. I hope to present this application along side DPX Grader at WIPTE 2010 should my paper be accepted.

There is just over a full week of school left in the semester and I am not finished yet. My class projects are not finished, I have a few other smaller projects and homework assignments standing between me and the end of the semester. Back to work!
